Electric Flip Instrument Panel Sub Assembly Harness
Электрический жгут приборной панели с электропереворотом
Arnés del subconjunto del panel de instrumentos con volteo eléctrico
The genuine Shacman X5000 Electric Flip Instrument Panel Sub Assembly Harness with OEM number DZ97189776924 is a precision‑engineered wiring assembly designed to integrate the electric cab tilt controls into the instrument panel of the Shacman X5000 heavy‑duty truck. This sub‑harness provides the critical electrical connection between the dashboard flip switch, indicator lamps, and the cab tilt control module, ensuring that the driver can safely and reliably operate the cab tilting system. Manufactured to exact Shacman specifications, DZ97189776924 features high‑grade cross‑linked polyethylene wire insulation, corrosion‑resistant terminals, and OEM‑specific connectors that guarantee a direct, plug‑and‑play installation without splicing or modifications. Every wire length, connector position, and mounting clip location matches the original instrument panel layout, ensuring a perfect fit behind the dashboard. This harness is essential for restoring or upgrading the electric cab tilt controls after harness damage, corrosion, or during a complete dashboard electrical system overhaul on the X5000.
A damaged or degraded instrument panel sub‑harness can cause intermittent or complete failure of the cab tilt controls, leaving the driver unable to safely raise or lower the cab for maintenance. Installing OEM DZ97189776924 restores full, reliable electrical connectivity to the tilt controls, ensuring that the driver can operate the system with confidence. This harness is essential for maintaining the safety and serviceability of the X5000.
Each DZ97189776924 harness is 100% continuity‑tested, inspected for terminal retention, and verified for correct connector orientation and protective routing. Choose genuine Shacman quality for reliable, long‑lasting instrument panel electrical performance.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ97189776924 |
| Product Name | Electric Flip Instrument Panel Sub Assembly Harness |
| Brand | Shacman (Genuine OEM) |
| Application | Shacman X5000 – Dashboard-mounted cab tilt controls |
| Harness Type | Electric flip instrument panel sub‑assembly wiring |
| Wire Gauge | 0.5 mm² to 2.5 mm² (various circuits, color‑coded per Shacman standard) |
| Insulation Material | Cross‑linked polyethylene (XLPE), heat‑resistant to 105°C |
| Connector Types | OEM‑specified 4‑pin, 6‑pin, and 8‑pin connectors (Tyco, Delphi, or equivalent) |
| Protective Covering | Anti‑abrasion TESA tape and flexible PVC conduit in high‑wear areas |
| Total Length | Approx. 1.2 m (includes branch sections for switch and indicator connections) |
| Terminal Material | Tin‑plated copper, gold‑plated for signal circuits |
| Temperature Range | -40°C to +105°C |
| Weight (approx.) | 0.35 kg |
| Standards | ISO 9001, IATF 16949, SAE J1128, Shacman Q/SC 789 |
The Shacman electric flip instrument panel sub assembly harness DZ97189776924 is engineered with exact wire lengths, connector placements, and routing paths that conform to the X5000’s dashboard architecture. Each circuit is color‑coded according to Shacman’s wiring diagrams, simplifying installation and reducing the risk of errors. The wires are made from oxygen‑free copper with cross‑linked polyethylene insulation, providing excellent conductivity, resistance to abrasion, and high‑temperature stability. The harness is wrapped with anti‑abrasion TESA tape and fitted with flexible PVC conduit in areas where it may come into contact with sharp edges, ensuring long‑term durability behind the dashboard. The integrated mounting clips are precisely positioned to match the instrument panel’s mounting points, eliminating the need for improvisation. The connectors feature positive locking mechanisms that prevent accidental disconnection due to vibration, and the terminals are tin‑ or gold‑plated to resist corrosion and maintain low contact resistance. Each harness is 100% continuity‑tested and subjected to a pull‑test on all terminals to verify retention force. Random samples are subjected to thermal cycling (-40°C to +105°C, 500 cycles), vibration (20G, 10‑2000 Hz), and salt spray (96 hours) to validate the wire insulation, conduit, and connector sealing. These rigorous engineering controls ensure that the DZ97189776924 harness provides reliable, trouble‑free service for the life of the vehicle.
This harness is specifically tailored for mounting behind the instrument panel, with connectors that align perfectly with the flip switch, indicator LEDs, and the main body harness interface. The routing is designed to avoid interference with other dashboard components and to facilitate easy access for future service. The robust construction ensures that the harness can withstand the vibrations and temperature variations typical of the cab environment, preventing intermittent faults and ensuring reliable cab tilt control.
The electric cab tilt system is a vital feature on the Shacman X5000, allowing drivers and technicians to safely and efficiently access the engine and powertrain for maintenance. The instrument panel sub‑harness DZ97189776924 is the crucial link between the driver’s controls (the flip switch and indicator lamps) and the cab tilt control module. A degraded or damaged harness can cause the cab tilt controls to become unresponsive, the indicator lamps to malfunction, or the system to operate erratically. This harness is designed with dedicated circuits for the up/down switch, the position indicator lamps, and the interlock safety switches, ensuring that the system operates as intended and that the driver receives clear feedback. The use of high‑quality wire insulation and sealed connectors prevents moisture ingress, which is a common cause of electrical faults in dashboard wiring. By restoring full electrical integrity, the DZ97189776924 harness ensures that the driver can operate the cab tilt with confidence, knowing that the controls will respond correctly and that the dashboard will accurately reflect the cab’s position.
Beyond the basic switch and indicator functions, this harness may also integrate connections for the cab tilt diagnostic interface, allowing for easier troubleshooting of system faults. The harness is also designed to be compatible with the vehicle’s body control module (BCM) or dedicated tilt controller, providing comprehensive system integration. In the event of a system fault, a properly functioning harness ensures that the BCM can accurately report the issue, speeding up the repair process. Using the genuine OEM harness also ensures that the wiring is correctly fused and protected, preventing damage to the control module. Fleet operators who rely on quick cab access for their maintenance routines will appreciate the reliability and ease of installation of this harness, which reduces downtime and improves workshop efficiency. The harness’s compact design and flexible routing also simplify its installation behind the dashboard, without interfering with other electronic components.
A reliable instrument panel sub‑harness ensures that the driver receives unambiguous feedback from the cab tilt system. The indicator lamps will illuminate correctly, and the flip switch will respond immediately, giving the driver full confidence in the system’s operation. The DZ97189776924 harness’s sealed connectors and high‑temperature insulation prevent faults that could cause false indications or unresponsive controls.
Installing the Shacman electric flip instrument panel sub assembly harness DZ97189776924 is a straightforward process for trained technicians. Begin by disconnecting the vehicle’s battery. Remove the instrument panel trim to access the back of the dashboard. Disconnect the old harness (if present) by releasing the mounting clips and unplugging the electrical connectors. Route the new harness along the original path, securing it with the integrated push‑in clips. Connect the harness to the flip switch, the indicator lamps, and the main body harness connector, ensuring that all connectors click securely into place. Reconnect the battery and test the cab tilt system: the flip switch should raise and lower the cab smoothly, and the dashboard indicators should show the correct status (e.g., “Tilt in Progress” or “Cab Latched”). If the system is equipped with an emergency stop, verify that it functions correctly. The harness is designed to be plug‑and‑play, requiring no wire splicing.
This harness is compatible with all Shacman X5000 models from 2015 onward, including the X5000 M12, heavy‑haul, and construction variants, as well as trucks with both manual and electric cab tilt systems. It directly replaces original part numbers DZ97189776923 and DZ97189776925. Applications include the instrument panel‑mounted cab tilt controls. Always verify the OEM marking DZ97189776924 on the harness label before installation. If the vehicle uses a different dashboard layout, ensure that the harness connectors match; if not, consult the vehicle’s wiring diagram for possible adapter requirements.
Keep a spare DZ97189776924 harness in your parts inventory for quick replacement in case of damage. After installation, test the cab tilt function several times to ensure smooth operation and check for any error codes in the BCM. If the system does not operate, check the fuse and relay associated with the cab tilt circuit, and verify that the harness is correctly connected to the power and ground sources.
Periodically inspect the harness behind the instrument panel for signs of chafing, loose connections, or damaged insulation. If the cab tilt controls become intermittent, check the harness connectors for corrosion or damage. The harness is designed to be maintenance‑free; however, if any damage is detected, replace the entire harness to avoid potential electrical faults. Ensure that the harness is not pinched by dashboard components when the trim is reinstalled.
Shacman X5000 trucks are used in a wide range of demanding applications, from construction and mining to long‑haul freight. The electric flip instrument panel sub assembly harness DZ97189776924 is designed to withstand the harsh conditions encountered in these environments. The cross‑linked polyethylene insulation resists heat, oil, and abrasion, while the flexible PVC conduit provides additional mechanical protection where needed. The connectors are sealed to prevent moisture and dust ingress, ensuring reliable electrical connections even in dusty or humid conditions. The harness is tested to operate reliably in temperatures from -40°C to +105°C, making it suitable for both arctic and desert climates. In mining operations, where trucks are frequently subjected to vibration and dust, the harness’s secure connectors and robust sheathing prevent intermittent faults. For highway fleets, the harness provides a reliable solution for the cab tilt controls, ensuring that maintenance can be performed quickly and safely. The harness’s plug‑and‑play design also simplifies the replacement process for fleet maintenance teams, allowing them to restore cab tilt control functionality efficiently.
The harness is also compatible with both standard and heavy‑duty cab tilt actuators, as it is designed to handle the control signals from the dashboard. The inclusion of dedicated ground and shield wires ensures that the flip switch and indicator lamps receive a clean signal, reducing the risk of false readings. By using the genuine Shacman harness, fleet operators can avoid the reliability issues associated with aftermarket wiring kits, which often use inferior wire and connectors. The DZ97189776924 harness is also backed by Shacman’s quality guarantee, providing peace of mind for operators who depend on their cab tilt system for routine maintenance. The harness’s color‑coded wires and labeled connectors also make it easier for technicians to troubleshoot any future issues, reducing diagnostic time.
1. Exact fitment: Designed specifically for X5000 instrument panel, with correct wire lengths and connector positions. 2. Superior materials: Cross‑linked polyethylene insulation, gold/tin‑plated terminals, and anti‑abrasion tape. 3. Plug‑and‑play installation: No cutting or splicing required, reducing installation time and errors. 4. Integrated mounting features: Includes all necessary clips for secure attachment behind the dashboard. 5. Full traceability: Batch‑coded with electrical test report and material certification. Aftermarket harnesses often use low‑grade wire, lack proper connectors, or have incorrect lengths, leading to intermittent faults and potential damage to the cab tilt controls. The genuine Shacman harness’s premium materials and exact engineering ensure reliable, long‑lasting performance. Investing in DZ97189776924 protects the vehicle’s cab tilt system, enhances driver safety, and reduces downtime. For fleets, standardizing on genuine harnesses ensures consistent quality and simplifies troubleshooting across all trucks.
A faulty instrument panel harness can lead to unresponsive cab tilt controls, delaying essential maintenance and causing frustration for drivers and technicians. Replacing a worn or damaged harness with the DZ97189776924 restores full functionality at a minimal cost, preventing these delays. The harness’s long life and corrosion resistance also reduce the frequency of replacements, saving labor and parts costs over the vehicle’s lifetime. Improved driver confidence in the system also contributes to overall satisfaction and safety.
Shacman’s electric flip instrument panel sub assembly harness DZ97189776924 is produced in an IATF 16949 certified facility. The wire is sourced from approved suppliers and undergoes strict inspection for conductor resistance and insulation thickness. The harness is assembled using automated crimping machines that ensure consistent terminal crimp height and pull‑off strength. The connectors are tested for insertion and retention forces. Each harness is 100% continuity‑tested, with every circuit verified for correct pin‑to‑pin continuity and proper routing. The harness is then wrapped with anti‑abrasion tape and fitted with protective conduit where required, and a final visual inspection is performed. Random samples are subjected to thermal shock (-40°C to +105°C, 500 cycles), vibration (20G, 10‑2000 Hz), and salt spray (96 hours) to validate durability. Only harnesses that pass all criteria are labeled with the OEM part number and packed in anti‑static bags.
This rigorous quality system ensures every DZ97189776924 harness performs identically to the original factory component. Consistency is critical for maintaining the reliability of the cab tilt controls and preventing electrical faults across your entire fleet. The facility also complies with REACH and RoHS environmental regulations, using only lead‑free, water‑based coatings.
Genuine Shacman electric flip instrument panel sub assembly harness DZ97189776924 is stocked by authorized distributors worldwide. Parts are supplied in sealed anti‑static bags, individually boxed with installation instructions and a wiring diagram, labeled with OEM part number and batch traceability. Bulk packs of 5 harnesses are available for fleet maintenance depots. Expedited shipping options are available through Shacman’s regional logistics hubs in North America, Europe, Asia, Africa, and the Middle East, with typical delivery within 3‑5 business days. Always purchase from certified dealers and verify the holographic authenticity label. Counterfeit harnesses may have incorrect wire gauges, poor connectors, or lack proper insulation, leading to shorts or fires.
For preventive maintenance programs, automated replenishment ensures your workshop never runs out of essential instrument panel harnesses. Keep a stock of DZ97189776924 on every service truck to handle cab tilt control repairs or harness replacements in the field. Many fleets replace these harnesses as part of a scheduled electrical system inspection to ensure reliable cab tilt operation and driver safety.
The Shacman Electric Flip Instrument Panel Sub Assembly Harness DZ97189776924 is a precision‑engineered wiring solution that provides a secure, reliable electrical connection for the cab tilt controls on X5000 trucks. With robust materials, exact fitment, and plug‑and‑play installation, this genuine OEM harness ensures safe, efficient cab access for maintenance, enhancing workshop productivity and driver confidence. By choosing DZ97189776924, you restore full cab tilt control functionality and protect your vehicle’s electrical system. Don’t trust generic aftermarket wiring – insist on genuine Shacman quality for every instrument panel harness replacement.
