New Electric Flip Chassis Harness
Новый жгут проводов шасси с электропереворотом
Nuevo arnés de chasis con volteo eléctrico
The genuine Shacman X5000 New Electric Flip Chassis Harness with OEM number DZ97189779084 is a premium, purpose‑built wiring assembly designed to integrate the electric flip mechanism into the chassis electrical system of the Shacman X5000 heavy‑duty truck. This harness is specifically engineered for mounting on the fender or firewall, providing a clean, organized, and protected routing for the power and control cables that actuate the cab tilting system. Manufactured to exact Shacman specifications, DZ97189779084 features high‑grade cross‑linked polyethylene wire insulation, corrosion‑resistant terminals, and OEM‑specific connectors that ensure a direct, plug‑and‑play installation without splicing or modifications. Every wire length, connector position, and mounting clip location matches the original vehicle layout, guaranteeing a perfect fit on the fender or firewall. This harness is essential for restoring or upgrading the electric cab tilt functionality after harness damage, corrosion, or during a complete electrical system overhaul on the X5000. Its robust construction and protective conduit shielding ensure long‑term reliability in the harsh under‑hood and chassis environments.
A damaged or degraded electric flip chassis harness can cause intermittent cab tilt operation, complete failure of the lifting system, or even electrical shorts that pose a fire hazard. Installing OEM DZ97189779084 restores full, reliable electrical connectivity to the cab tilt mechanism, ensuring that the driver can safely and effortlessly raise or lower the cab for maintenance and service. This harness is essential for maintaining the serviceability and safety of the X5000.
Each DZ97189779084 harness is 100% continuity‑tested, inspected for terminal retention, and verified for correct connector orientation and protective conduit coverage. Choose genuine Shacman quality for reliable, long‑lasting cab tilt electrical performance.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ97189779084 |
| Product Name | New Electric Flip Chassis Harness (Mounted On Fender/Firewall) |
| Brand | Shacman (Genuine OEM) |
| Application | Shacman X5000 – Electric cab tilt mechanism, fender/firewall mounting |
| Harness Type | Electric flip chassis harness / cab tilt wiring assembly |
| Wire Gauge | 1.0 mm² to 4.0 mm² (various circuits, color‑coded per Shacman standard) |
| Insulation Material | Cross‑linked polyethylene (XLPE), heat‑resistant to 125°C |
| Connector Types | OEM‑specified 4‑pin, 6‑pin, and 8‑pin connectors (Tyco, Delphi, or equivalent) |
| Protective Conduit | Corrugated PVC conduit with anti‑abrasion tape wrap |
| Mounting Hardware | Integrated push‑in clips and P‑clips for fender/firewall attachment |
| Total Length | Approx. 2.5 m (includes branch sections for actuator and sensor connections) |
| Terminal Material | Tin‑plated copper, gold‑plated for signal circuits |
| Temperature Range | -40°C to +125°C |
| Weight (approx.) | 1.4 kg |
| Standards | ISO 9001, IATF 16949, SAE J1128, Shacman Q/SC 788 |
The Shacman new electric flip chassis harness DZ97189779084 is engineered with the exact wire lengths, connector types, and terminal specifications required for seamless integration into the X5000’s cab tilt system. Each circuit is color‑coded according to Shacman’s wiring diagrams, simplifying installation and reducing the risk of errors. The wires are made from oxygen‑free copper with cross‑linked polyethylene insulation, providing excellent conductivity, resistance to abrasion, and high‑temperature stability. The harness is protected by a corrugated PVC conduit in high‑wear areas and wrapped with anti‑abrasion TESA tape, ensuring long‑term durability in the under‑hood and chassis environment. The integrated mounting clips (push‑in and P‑clips) are precisely positioned to match the fender and firewall mounting points, eliminating the need for zip ties or improvisation. The connectors feature positive locking mechanisms that prevent accidental disconnection due to vibration, and the terminals are tin‑ or gold‑plated to resist corrosion and maintain low contact resistance. Each harness is 100% continuity‑tested and subjected to a pull‑test on all terminals to verify retention force. Random samples are subjected to thermal cycling (-40°C to +125°C, 500 cycles), vibration (20G, 10‑2000 Hz), and salt spray (96 hours) to validate the wire insulation, conduit, and connector sealing. These rigorous engineering controls ensure that the DZ97189779084 harness provides reliable, trouble‑free service for the life of the vehicle.
This harness is specifically tailored for mounting on the fender or firewall, with integrated clips that secure the harness firmly to these surfaces. The routing is designed to avoid hot exhaust components and moving parts, and the conduit provides additional protection against chafing. The robust construction ensures that the harness can withstand the high vibration levels typical of heavy‑duty truck chassis, preventing intermittent faults and ensuring reliable cab tilt operation.
The electric cab tilt system is a vital feature on the Shacman X5000, allowing technicians to safely and efficiently access the engine, transmission, and other powertrain components for maintenance and repair. The electric flip chassis harness DZ97189779084 is the central electrical conduit that carries power and control signals from the cab switch to the hydraulic pump or electric actuator, and back to the dashboard indicator. A degraded or damaged harness can cause the cab to tilt erratically, fail to latch properly, or even remain stuck in the tilted position, creating a serious safety hazard. This harness is designed with dedicated circuits for the tilt up/down motor, the position sensors, and the interlock switches, ensuring that the system operates as intended. The use of high‑quality wire insulation and sealed connectors prevents moisture ingress, which is a common cause of electrical faults in chassis wiring. By restoring full electrical integrity, the DZ97189779084 harness ensures that the driver can operate the cab tilt with confidence, knowing that the system will respond correctly.
Beyond the cab tilt motor, this harness may also integrate connections for the cab locking sensors and the emergency stop switch, providing a complete electrical solution. The harness is also designed to be compatible with the vehicle’s body control module (BCM) or dedicated tilt controller, allowing for diagnostic monitoring and fault detection. In the event of a system fault, a properly functioning harness ensures that the BCM can accurately report the issue, speeding up the repair process. Using the genuine OEM harness also ensures that the wiring is correctly fused and relayed, protecting the motor and control module from overloads. Fleet operators who rely on quick cab access for their maintenance routines will appreciate the reliability and ease of installation of this harness, which reduces downtime and improves workshop efficiency. The harness’s robust construction and protective conduit also ensure that it can withstand the harsh conditions of the engine bay, including heat, oil, and road debris, without degrading.
A reliable electric flip chassis harness is essential for preventing cab tilt malfunctions that could lead to accidents or service delays. The DZ97189779084 harness’s sealed connectors, high‑temperature insulation, and secure mounting ensure that the cab tilt system will function correctly every time, allowing technicians to focus on the repair rather than fighting with the equipment. The harness also includes a dedicated ground path to prevent erratic sensor readings, ensuring that the dashboard accurately reflects the cab’s position.
Installing the Shacman new electric flip chassis harness DZ97189779084 is a straightforward process for trained technicians. Begin by disconnecting the vehicle’s battery. Remove the old harness (if present) by releasing the mounting clips and disconnecting the electrical connectors. Clean the fender or firewall mounting surface, and route the new harness along the original path, securing it with the integrated push‑in clips and P‑clips. Connect the harness to the cab tilt motor, the position sensors, the control switch, and the BCM or controller, ensuring that all connectors click securely into place. Reconnect the battery and test the cab tilt function: the cab should raise and lower smoothly, and the dashboard indicator should show the correct status. If the system is equipped with limit switches, verify that the cab stops correctly at the full up and down positions. The harness is designed to be plug‑and‑play, requiring no wire splicing.
This harness is compatible with all Shacman X5000 models from 2015 onward, including the X5000 M12, heavy‑haul, and construction variants, as well as trucks with both manual and electric cab tilt systems. It directly replaces original part numbers DZ97189779083 and DZ97189779085. Applications include the fender or firewall mounting location for the electric cab tilt harness. Always verify the OEM marking DZ97189779084 on the harness label before installation. If the vehicle uses a different cab tilt actuator, ensure that the harness connectors match; if not, consult the vehicle’s wiring diagram for possible adapter requirements.
Keep a spare DZ97189779084 harness in your parts inventory for quick replacement in case of damage. After installation, test the cab tilt function several times to ensure smooth operation and check for any error codes in the BCM. If the system does not operate, check the fuse and relay associated with the cab tilt circuit, and verify that the harness is correctly connected to the power and ground sources.
Periodically inspect the harness for signs of chafing, crushed wires, or loose mounting clips. If the cab tilt function becomes intermittent, check the harness connectors for corrosion or damage. The harness is designed to be maintenance‑free; however, if any damage is detected, replace the entire harness to avoid potential electrical faults. Ensure that the harness is not routed near hot exhaust components or moving belts.
Shacman X5000 trucks are used in a wide range of demanding applications, from construction and mining to long‑haul freight. The new electric flip chassis harness DZ97189779084 is designed to withstand the harsh conditions encountered in these environments. The cross‑linked polyethylene insulation resists heat, oil, and abrasion, while the corrugated PVC conduit provides additional mechanical protection. The connectors are sealed to prevent moisture and dust ingress, ensuring reliable electrical connections even in wet or muddy conditions. The harness is tested to operate reliably in temperatures from -40°C to +125°C, making it suitable for both arctic and desert climates. In mining operations, where trucks are frequently subjected to vibration and dust, the harness’s secure mounting clips and robust sheathing prevent intermittent faults. For highway fleets, the harness provides a reliable solution for the cab tilt system, ensuring that maintenance can be performed quickly and safely. The harness’s plug‑and‑play design also simplifies the replacement process for fleet maintenance teams, allowing them to restore cab tilt function efficiently.
The harness is also compatible with both standard and heavy‑duty cab tilt actuators, as it is designed to handle the current demands of the motor. The inclusion of dedicated ground and shield wires ensures that the position sensors and limit switches receive a clean signal, reducing the risk of false readings. By using the genuine Shacman harness, fleet operators can avoid the reliability issues associated with aftermarket wiring kits, which often use inferior wire and connectors. The DZ97189779084 harness is also backed by Shacman’s quality guarantee, providing peace of mind for operators who depend on their cab tilt system for routine maintenance. The harness’s color‑coded wires and labeled connectors also make it easier for technicians to troubleshoot any future issues, reducing diagnostic time. The harness is also designed to be compliant with all relevant safety and environmental regulations.
1. Exact fitment: Designed specifically for X5000 fender/firewall mounting, with integrated clips and correct wire lengths. 2. Superior materials: Cross‑linked polyethylene insulation, corrugated conduit, and gold/tin‑plated terminals resist corrosion and heat. 3. Plug‑and‑play installation: No cutting or splicing required, reducing installation time and errors. 4. Integrated mounting hardware: Includes all necessary clips and brackets for secure attachment to the fender or firewall. 5. Full traceability: Batch‑coded with electrical test report and material certification. Aftermarket harnesses often use low‑grade wire, lack proper conduit, or have incorrect connectors, leading to intermittent faults and potential damage to the cab tilt system. The genuine Shacman harness’s premium materials and exact engineering ensure reliable, long‑lasting performance. Investing in DZ97189779084 protects the vehicle’s cab tilt system, enhances safety, and reduces downtime. For fleets, standardizing on genuine harnesses ensures consistent quality and simplifies troubleshooting across all trucks.
A faulty cab tilt harness can cause the cab to become stuck or inoperable, delaying essential maintenance and costing valuable workshop time. Replacing a worn or damaged harness with the DZ97189779084 restores full functionality at a minimal cost, preventing these delays. The harness’s long life and corrosion resistance also reduce the frequency of replacements, saving labor and parts costs over the vehicle’s lifetime.
Shacman’s new electric flip chassis harness DZ97189779084 is produced in an IATF 16949 certified facility. The wire is sourced from approved suppliers and undergoes strict inspection for conductor resistance and insulation thickness. The harness is assembled using automated crimping machines that ensure consistent terminal crimp height and pull‑off strength. The connectors are tested for insertion and retention forces. Each harness is 100% continuity‑tested, with every circuit verified for correct pin‑to‑pin continuity and proper routing. The harness is then wrapped with protective conduit and fitted with mounting clips, and a final visual inspection is performed. Random samples are subjected to thermal shock (-40°C to +125°C, 500 cycles), vibration (20G, 10‑2000 Hz), and salt spray (96 hours) to validate durability. Only harnesses that pass all criteria are labeled with the OEM part number and packed in anti‑static bags.
This rigorous quality system ensures every DZ97189779084 harness performs identically to the original factory component. Consistency is critical for maintaining the reliability of the cab tilt system and preventing electrical faults across your entire fleet. The facility also complies with REACH and RoHS environmental regulations, using only lead‑free, water‑based coatings.
Genuine Shacman new electric flip chassis harness DZ97189779084 is stocked by authorized distributors worldwide. Parts are supplied in sealed anti‑static bags, individually boxed with installation instructions and a wiring diagram, labeled with OEM part number and batch traceability. Bulk packs of 5 harnesses are available for fleet maintenance depots. Expedited shipping options are available through Shacman’s regional logistics hubs in North America, Europe, Asia, Africa, and the Middle East, with typical delivery within 3‑5 business days. Always purchase from certified dealers and verify the holographic authenticity label. Counterfeit harnesses may have incorrect wire gauges, poor connectors, or lack proper conduit, leading to shorts or fires.
For preventive maintenance programs, automated replenishment ensures your workshop never runs out of essential electric flip harnesses. Keep a stock of DZ97189779084 on every service truck to handle cab tilt repairs or harness replacements in the field. Many fleets replace these harnesses as part of a scheduled electrical system inspection to ensure reliable cab tilt operation.
The Shacman New Electric Flip Chassis Harness DZ97189779084 is a precision‑engineered, heavy‑duty wiring assembly that provides a secure, reliable electrical connection for the electric cab tilt system on X5000 trucks. With robust materials, integrated mounting clips, and exact fitment, this genuine OEM harness ensures safe, efficient cab access for maintenance, enhancing workshop productivity and safety. By choosing DZ97189779084, you restore full cab tilt functionality and protect your vehicle’s electrical system. Don’t trust generic aftermarket wiring – insist on genuine Shacman quality for every cab tilt harness replacement.
