Radiator Support Bracket Assembly
Кронштейн Радиатора
Soporte del Radiador
OEM Radiator Support Bracket Assembly DZ97259531800 precision‑engineered for the Shacman X5000 cooling system. This robust DZ97259531800 mounting structure secures the radiator to the chassis frame, maintaining proper alignment and isolating vibration.
Fabricated from high‑strength structural steel with durable anti‑corrosion coating, the Radiator Support Bracket Assembly DZ97259531800 withstands the combined weight of the radiator and coolant while resisting chassis flex and road shock.
Replacing a damaged or corroded bracket assembly with the genuine DZ97259531800 component restores proper radiator support and prevents the stress that leads to core damage and coolant leaks.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ97259531800 |
| Product Name | Radiator Support Bracket Assembly |
| Brand / Model | Shacman X5000 |
| Material | High‑Strength Structural Steel with Black Powder Coating |
| Assembly Components | Upper bracket, lower support, rubber isolators |
| Mounting Hole Diameter | 12.00 mm (chassis frame bolt points) |
| Radiator Mount Pattern | 4‑point mounting with vibration isolators |
| Load Capacity | Supports up to 65 kg radiator assembly |
| Corrosion Protection | Black powder coating, 600 hours salt spray rated |
| Application | Shacman X5000 radiator mounting to chassis frame |
The DZ97259531800 radiator support bracket assembly is the structural interface between the cooling module and the Shacman X5000 chassis. It must safely support the radiator weight while accommodating chassis flex and vibration.
A fully filled radiator and intercooler assembly can weigh over 60 kilograms. The brackets transfer this static load and the dynamic forces from road shock and chassis twisting into the frame without deformation or fatigue cracking.
The Radiator Support Bracket Assembly DZ97259531800 incorporates rubber isolators at the radiator mounting points. These isolators absorb vibration that would otherwise transmit into the radiator core, causing solder joint fatigue and leaks.
The DZ97259531800 bracket assembly is manufactured from high‑strength structural steel that provides the necessary rigidity to maintain radiator position while resisting the cyclical stresses of vehicle operation.
The black powder coating applied to all bracket surfaces creates a durable barrier against moisture, road salt, and stone impact. This coating maintains its protective properties through years of exposure to harsh environments.
The DZ97259531800 bracket assembly mounts to pre‑drilled holes in the chassis frame using high‑strength bolts. The rubber isolators must be correctly positioned before the radiator is lowered into place.
All bolts should be started by hand and tightened progressively to the specified torque. The radiator should sit squarely on its mounts without any preload that could stress the core or the hose connections.
Each production batch of DZ97259531800 bracket assemblies is sampled for static load testing at three times the rated capacity. The assembly must show no permanent deformation or cracking after the test load is removed.
Coating thickness and adhesion are verified on sample brackets using eddy current measurement and cross‑hatch testing. The powder coating must meet the specified minimum thickness across all functional surfaces.
Rust staining or bubbling of the powder coating on the DZ97259531800 bracket indicates that corrosion has penetrated the protective layer. If left unaddressed, this can progress to metal loss and structural weakening.
Cracks propagating from bolt holes or welded joints are evidence of fatigue damage. Cracked brackets must be replaced immediately to prevent radiator detachment that could cause sudden coolant loss and engine overheating.
During cooling system service, the support brackets and rubber isolators should be inspected for condition. Worn or collapsed isolators allow excessive radiator movement and should be replaced along with any damaged brackets.
The DZ97259531800 bracket assembly is specifically configured for the Shacman X5000 radiator dimensions and chassis frame hole patterns. It matches the factory‑specified mounting locations exactly.
Fleet operators should maintain spare bracket assemblies and isolators in their cooling system parts inventory. Prompt replacement of damaged brackets prevents the radiator damage that causes vehicle downtime.
Aftermarket support brackets with inadequate material strength or incorrect dimensions can compromise radiator security. We supply only the authentic Shacman X5000 Radiator Support Bracket Assembly DZ97259531800.
Each assembly is individually packaged with protective wrapping to prevent coating damage during transit. The part number DZ97259531800 is clearly displayed on both the component label and shipping documentation.
Our international supply chain maintains strategic inventory levels to support fleet operators and service facilities worldwide. Genuine DZ97259531800 brackets are dispatched promptly to minimize vehicle downtime.
Complete radiator support bracket assembly with rubber isolators and mounting hardware. Protective packaging prevents coating damage during transit.
Expert guidance on bracket installation and radiator alignment procedures. We help ensure your DZ97259531800 assembly provides secure long‑term cooling system support.
For current stock availability and delivery scheduling on the genuine Radiator Support Bracket Assembly DZ97259531800, please use the contact buttons above.
