Generator, Alternator
Генератор
Alternador
OEM Generator, Alternator 1004133997 manufactured to exact Shacman X5000 specifications. This heavy‑duty 1004133997 alternator delivers consistent electrical power to charge the battery and supply all vehicle electrical systems under demanding operating conditions.
Built with high‑efficiency copper windings and heavy‑duty bearings, the Generator, Alternator 1004133997 provides reliable output across the full engine speed range, ensuring that lights, electronics, and accessories receive stable voltage.
Installing the genuine 1004133997 alternator restores proper charging system function and prevents the battery discharge that leads to vehicle downtime.
| Parameter | Specification |
|---|---|
| OEM Part Number | 1004133997 |
| Product Name | Generator, Alternator |
| Brand / Model | Shacman X5000 |
| Rated Voltage | 28 Volts DC |
| Rated Current Output | 150 Amperes |
| Regulator Type | Internal solid‑state voltage regulator |
| Bearing Type | Double‑sealed ball bearings, front and rear |
| Pulley Type | Multi‑ribbed belt pulley, 8‑groove |
| Rotation Direction | Clockwise (viewed from pulley end) |
| Application | Shacman X5000 electrical charging system |
The 1004133997 generator, alternator is the primary source of electrical energy for the Shacman X5000 once the engine is running. It converts mechanical energy from the engine’s serpentine belt into the electrical power that operates every system.
Modern heavy trucks depend on stable electrical supply for engine management computers, electronic fuel injection, lighting systems, HVAC blowers, and communication equipment. The Generator, Alternator 1004133997 meets these continuous demands.
A failing alternator causes battery voltage to drop progressively during operation. This triggers warning lights, causes electronic systems to malfunction, and eventually leads to complete electrical shutdown and vehicle immobilization.
The 1004133997 alternator features precision‑wound copper stator coils that maximize magnetic flux conversion efficiency. This design reduces internal resistance and minimizes the heat generation that degrades electrical components.
The rotor assembly uses high‑grade copper slip rings and long‑life carbon brushes that maintain consistent field current delivery. This ensures stable output voltage regulation across the alternator’s entire speed range.
Mounting the 1004133997 alternator requires aligning its mounting ears with the engine bracket and installing the pivot and adjustment bolts. The serpentine belt must be routed correctly around all driven accessories.
Proper belt tension is critical for alternator performance and bearing life. Use a belt tension gauge to set the tension to Shacman specifications. An under‑tensioned belt slips under load, while over‑tensioning damages bearings.
Every 1004133997 alternator is tested on a dynamometer that simulates engine drive speeds from idle to maximum RPM. Output current, voltage regulation, and ripple voltage are measured and recorded for each unit.
Thermal cycling tests subject the alternator to repeated heat‑soak and cool‑down cycles while monitoring performance. This validation ensures that the internal electronics and bearings survive under‑hood temperature extremes.
A glowing battery warning light on the instrument panel is the most obvious indication of a charging system problem related to the 1004133997 alternator. This light illuminates when system voltage falls below the normal range.
Dimming headlights at idle that brighten with increased engine speed suggest worn brushes or a failing voltage regulator within the Generator, Alternator 1004133997. Bearing noise indicates impending mechanical failure.
A comprehensive charging system test should be performed whenever electrical issues are suspected. This test measures output under load and verifies that the alternator meets its rated current specification.
The 1004133997 alternator is specifically configured for the Shacman X5000 electrical system. Its mounting bracket pattern, pulley alignment, and electrical connector are matched to this vehicle platform.
When replacing the alternator, the serpentine belt should be inspected and replaced if worn. The battery should also be tested, as a failing battery can place excessive load on the new 1004133997 unit.
Remanufactured or counterfeit alternators may use inferior bearings and substandard electronic components. We supply only the authentic Shacman X5000 Generator, Alternator 1004133997 with complete OEM warranty coverage.
Each alternator is packaged in a custom‑fit carton with protective inserts to prevent damage during shipping. The part number 1004133997 is clearly displayed on both the unit and the packaging.
Our global distribution network maintains adequate stock levels to support fleet operators and independent workshops. Genuine 1004133997 alternators are available for immediate dispatch to minimize vehicle downtime.
Complete alternator assembly with internal regulator, pulley, and connector. Protective packaging ensures the unit arrives ready for immediate installation.
Expert guidance on alternator installation and charging system diagnosis. We help ensure your 1004133997 alternator provides reliable electrical power.
For current stock availability and pricing on the genuine Generator, Alternator 1004133997, please use the contact buttons above.
