OEM Harness Bracket 611600080106 precision‑formed for the Shacman X5000 heavy‑duty truck. This essential 611600080106 mounting component anchors electrical wiring harnesses at critical engine locations, maintaining proper routing and preventing insulation damage.
Constructed from heavy‑gauge steel with a durable multi‑layer coating system, the Harness Bracket 611600080106 resists corrosion, vibration fatigue, and the mechanical stresses imposed by continuous commercial vehicle operation.
Replacing damaged brackets with the genuine 611600080106 component restores factory‑spec harness support and protects the vehicle electrical system from preventable failures.
| Parameter | Specification |
|---|---|
| OEM Part Number | 611600080106 |
| Product Name | Harness Bracket |
| Brand / Model | Shacman X5000 |
| Material | Hot‑Dip Galvanized Steel with Passivation Treatment |
| Bracket Length | 142.00 mm |
| Bracket Width | 44.00 mm |
| Mounting Hole Diameter | 10.00 mm with captive nut M8 thread |
| Harness Retention | Formed channel with integrated clamping strap |
| Zinc Coating Thickness | Minimum 55 microns hot‑dip galvanized |
| Application | Shacman X5000 engine block and chassis harness support |
The 611600080106 harness bracket is a fundamental component of the Shacman X5000 electrical architecture. It fixes wiring harnesses at designated anchor points, preventing the movement that leads to chafing, connector fatigue, and short circuits.
In the harsh operating environment of a heavy truck, unsupported wiring is quickly damaged by engine vibration, road shock, and temperature extremes. The Harness Bracket 611600080106 absorbs these forces and keeps wiring securely positioned.
A single failed bracket can initiate a chain reaction of electrical problems. As one bracket breaks, additional stress transfers to adjacent supports, potentially causing progressive bracket failure and widespread harness damage.
The 611600080106 bracket undergoes hot‑dip galvanizing, a process that immerses the fabricated steel in molten zinc to form a metallurgically bonded coating. This coating provides decades of corrosion protection in outdoor exposure.
A subsequent passivation treatment seals the zinc surface and prevents the formation of white rust during storage and the initial service period. This treatment extends the aesthetic appearance and functional life of the bracket.
The 611600080106 bracket features an integrated captive nut that simplifies installation by eliminating the need for a separate nut and washer. The mounting bolt threads directly into the bracket from the accessible side.
The wiring harness is placed into the formed channel and secured with the integrated clamping strap. This one‑piece design ensures that the correct retention force is applied without risk of over‑tightening damage.
Every production lot of 611600080106 brackets is sampled for zinc coating thickness measurement using magnetic induction gauges. The coating must exceed 55 microns on all accessible surfaces to pass inspection.
Bend testing of the integrated strap confirms that it can withstand repeated flexing without cracking. This ensures that the strap retains its clamping force through multiple service operations over the vehicle’s lifetime.
A detached 611600080106 bracket may be discovered during routine inspection as a loose component hanging from the wiring harness. The harness itself may show signs of rubbing against adjacent metal surfaces.
Corrosion at the mounting point can weaken the bracket‑to‑structure connection. If the mounting boss on the engine or chassis shows rust damage, it should be cleaned and treated before installing a new Harness Bracket 611600080106.
When performing engine repairs that require harness disconnection, all brackets should be inspected for damage. This is an opportune time to replace any brackets showing signs of fatigue before they fail in service.
The 611600080106 bracket is specifically designed for designated harness attachment locations on the Shacman X5000 model. Its formed geometry matches the harness diameter and routing angle at that position.
Maintaining a supply of genuine 611600080106 brackets in your parts inventory supports efficient repairs and ensures that wiring harnesses are always properly supported after any service procedure.
Aftermarket brackets may use thinner material or inadequate corrosion protection that fails prematurely. We supply only the authentic Shacman X5000 Harness Bracket 611600080106 with complete OEM quality assurance.
Each bracket is individually packaged to protect the galvanized surface during shipping and handling. The part number 611600080106 is clearly visible on the packaging for rapid identification.
Our international supply chain maintains stock levels that support both scheduled maintenance programs and emergency repairs. Genuine 611600080106 brackets are dispatched promptly to minimize vehicle downtime.
Single harness bracket with integrated clamping strap and captive nut. Protective wrapping prevents coating damage during transit.
Expert guidance on harness bracket installation and wiring routing requirements. We help ensure your 611600080106 brackets deliver reliable performance.
For current stock availability and pricing on the genuine Harness Bracket 611600080106, please use the contact buttons above.
