Shacman X5000 OEM 1013998001 Fuel Fine Filter – High‑Efficiency Contamination Removal for Common Rail Systems

Technical Specifications – Fuel Fine Filter 1013998001

Advanced Filtration & Water Separation Technology

The Shacman fuel fine filter 1013998001 uses a three‑stage filtration process. First, a coalescing layer removes bulk water and large particles. Second, a deep‑bed microglass media captures particles down to 5 microns with >98% efficiency. Third, a hydrophobic screen repels residual water, which then falls into a transparent bowl for visual inspection. The pleated design provides a large filtration area, ensuring low flow restriction even as the filter loads with contaminants. The integrated sedimenter collects water and debris, and a brass drain valve allows easy service without removing the filter. The filter element is reinforced with an inner steel core to prevent collapse under high flow or cold‑start pressure surges. The water bowl is made from high‑impact polyamide that resists cracking from biodiesel and winter additives, and it remains transparent for years.

Each filter is 100% leak‑tested and burst‑tested to 10 bar. Random samples are subjected to 1,000 hours of flow fatigue, vibration, and thermal cycling. The media’s pore size distribution is verified by mercury intrusion porosimetry. These engineering choices guarantee that the 1013998001 filter provides consistent protection over the entire service interval.

High Dirt Holding Capacity & Low Restriction

The 1013998001 filter can hold up to 50 grams of sediment before reaching terminal pressure drop. Its low initial pressure drop (≤0.05 bar at rated flow) ensures the lift pump does not work excessively, preserving its life. The filter’s design also minimizes flow pulsation, reducing stress on downstream components.

Critical Role in Common Rail Fuel System Protection

The common rail system operates with extremely tight clearances (1‑2 microns) between plungers and barrels. Any particle larger than 5 microns can cause scuffing, galling, and eventual pump seizure. Water in fuel causes cavitation erosion and rust, leading to injector needle sticking. The fuel fine filter 1013998001 is the last line of defense before the high‑pressure pump. By removing 98% of particles ≥5µm and over 95% of free water, it prevents abrasive wear and corrosion. Fleet data shows that engines using genuine Shacman filters experience 80% fewer high‑pressure pump failures compared to those using low‑quality substitutes.

A neglected filter becomes restricted, causing fuel starvation at high loads. The engine may de‑rate or stall. The 1013998001 filter’s high dirt holding capacity (up to 50g) allows it to last the full recommended change interval (40,000‑60,000 km) under normal fuel quality. The built‑in water bowl allows quick visual checks: if water is seen, it can be drained via the valve without replacing the filter. The filter also includes a replaceable gasket set to ensure a leak‑free seal between the filter head and the element. Using genuine filters also maintains the fuel system warranty, as many manufacturers void coverage if non‑OEM filters are used.

For engines with biodiesel (B20) or ultra‑low sulfur diesel (ULSD), the filter media is specially treated to resist swelling and chemical degradation. The water separation efficiency remains high even with emulsified water common in biodiesel. The 1013998001 filter meets the SAE J1839 water separation standard.

Preventing Injector & Pump Wear

A single 10‑micron particle can scratch a precision‑fitted pump plunger, reducing efficiency and increasing fuel return. The 1013998001 filter’s 5‑micron rating ensures that such particles are captured, preserving the pump’s volumetric efficiency and extending injector life. The water separator also prevents microbial growth (diesel bug) that thrives at the fuel‑water interface.

Installation & Compatibility Guide

Replacing the fuel fine filter 1013998001 is a standard maintenance task. Ensure the engine is cold, relieve fuel system pressure, place a container under the filter, and unscrew the filter by hand or with a strap wrench. Clean the mounting head, lubricate the new filter’s O‑ring with clean diesel, and spin the new filter on until the gasket contacts the head, then tighten an additional 3/4 turn. Open the drain valve briefly to prime, or use the hand primer on the filter head. Start the engine and check for leaks. Bleed the system if necessary.

This filter is compatible with all Shacman X5000 models equipped with WP13, WP15, or ISM common rail engines from 2015 onward. It directly replaces original part numbers 1013998000 and 1013998002. Applications include the secondary (fine) filter position, typically after the primary fuel/water separator. Always verify the OEM marking 1013998001 on the filter can. Do not attempt to clean and reuse the filter; it is designed for single use only. Always change the filter at the recommended interval or more frequently if operating with poor fuel quality.

When replacing the filter, inspect the water bowl for cracks and the drain valve for proper sealing. Keep a spare 1013998001 filter in your parts inventory to avoid extended downtime. After installation, run a diagnostic fuel pressure test to confirm no excessive restriction.

Maintenance & Inspection Tips

Visually check the water bowl every week. If water is visible (separate layer at the bottom), drain it using the valve. Change the filter every 40,000‑60,000 km or when the pressure drop exceeds 0.7 bar (if equipped with a restriction gauge). Also replace the filter if the engine has been run on contaminated fuel or after major fuel system repairs.

Applications & Harsh Environment Performance

Shacman X5000 trucks operate in mining, construction, oilfields, and long‑haul freight – where fuel quality can be inconsistent. The 1013998001 filter is tested to withstand 500 hours of vibration, 480 hours of salt spray, and 1,000 hours of exposure to B20 biodiesel at 80°C. The water bowl material resists crazing from road salt and temperature cycling. In arctic conditions, the filter’s steel core prevents collapse from waxed fuel during cold starts. The drain valve is designed not to freeze or leak. In dusty environments, the filter’s high dirt‑holding capacity prevents premature clogging.

For mining dump trucks, the filter handles the high vibration of the engine without loosening its seal. The filter’s robust construction prevents external fuel leaks that could create fire hazards. For highway fleets, the filter ensures consistent injector performance, which directly impacts fuel economy and emissions. The water separator reduces the chance of DPF damage from high sulfur or water‑induced corrosion.

5 Advantages of Genuine Shacman OEM 1013998001

1. Precision filtration: 5‑micron absolute rating protects tight‑tolerance injection components. 2. High water separation: >95% efficiency prevents corrosion and cavitation. 3. Heavy‑duty construction: Steel core, robust can, crack‑resistant bowl. 4. Long service life: High dirt holding capacity (50g) reduces change frequency. 5. Full traceability: Batch‑coded with test report and filtration efficiency certificate. Aftermarket filters often use poor media that allows particles through or collapses under flow, leading to pump failure. The genuine Shacman filter’s premium media and construction ensure reliable protection. Investing in 1013998001 prevents injector seizures, pump failure, and costly fuel system overhauls. For fleets, standardizing on genuine filters reduces downtime and maintains warranty coverage. The cost of one pump replacement far exceeds a lifetime of genuine filters.

Return on Investment for Fleets

A single injector set replacement costs several thousand dollars. Using genuine 1013998001 filters every 40,000 km adds minimal cost but extends injector life by 2‑3 times, saving tens of thousands over the truck’s life. The water separator also reduces fuel polishing costs.

Quality Assurance & Manufacturing Standards

Shacman’s fuel fine filter 1013998001 is produced in an IATF 16949 certified facility. The media pleating is done on automated machines with ultrasonic cutting to prevent fiber shedding. The end caps are bonded using high‑strength epoxy cured in controlled ovens. Each filter is tested for burst strength (10 bar) and collapse pressure (≥5 bar). Random samples are tested for filtration efficiency (ISO 19438), water separation (ISO 16332), and flow restriction. The assembly is 100% leak‑tested with pressurized air and soap solution. Only filters that pass all criteria are laser‑marked with the OEM part number and packed in sealed poly bags.

This rigorous quality system ensures every 1013998001 filter performs identically to the original factory component. Consistency is critical for maintaining fuel system cleanliness and preventing unexpected failures across your entire fleet.

Global Supply Chain & Availability

Genuine Shacman fuel fine filter 1013998001 is stocked by authorized distributors worldwide. Parts are supplied in sealed poly bags, individually boxed, with OEM part number and batch traceability. Bulk packs of 12 filters are available for fleet maintenance depots. Expedited shipping options are available through Shacman’s regional logistics hubs in North America, Europe, Asia, Africa, and the Middle East, with typical delivery within 3‑5 business days. Always purchase from certified dealers and verify the holographic authenticity label. Counterfeit filters may lack proper media, water separation ability, or burst strength, leading to catastrophic fuel system damage.

For preventive maintenance programs, automated replenishment ensures your workshop never runs out of essential fuel filters. Keep a stock of 1013998001 on every service truck to handle filter changes in the field. Many fleets replace the fine filter at every oil change, ensuring peak fuel system protection.
