The genuine Shacman OEM 611600040076 Engine Hanger Plate is a heavy-duty lifting and support bracket specifically designed for the Shacman X5000 truck series. Part number 611600040076 is manufactured from high-strength forged steel, providing a secure attachment point for engine lifting during removal, installation, or major overhaul. This engine hanger plate ensures safe, balanced handling of the WP12/WP13 engine without risk of damage to surrounding components.
Engineered to withstand the full weight of the X5000 engine (approximately 950 kg), the 611600040076 plate features precision-drilled mounting holes that align perfectly with factory threaded bosses on the cylinder block. For Shacman X5000 fleet operators, workshop technicians, and rebuilders, using the genuine OEM hanger plate guarantees safe lifting, corrosion resistance, and long service life even in high-use environments.
Every Shacman engine hanger plate is forged, heat-treated, and zinc-plated to resist rust and mechanical stress. The integrated lifting eye is designed to accept standard shackles and hooks. Trust OEM 611600040076 for professional engine handling in any heavy-duty repair or assembly operation.
| Parameter | Specification |
|---|---|
| OEM Part Number | 611600040076 |
| Product Name | Engine Hanger Plate / Lifting Bracket |
| Brand / Engine | Shacman X5000 (WP12 / WP13) |
| Material | Forged high-strength carbon steel (Grade 8.8 equivalent) |
| Thickness | 12.0 mm ±0.2 mm |
| Mounting Hole Diameter (x2) | 16.5 mm (for M16 bolts) |
| Lifting Eye Hole Diameter | 25.0 mm |
| Safe Working Load (SWL) | 1200 kg (vertical lift) |
| Break Load (min.) | 4800 kg (4x safety factor) |
| Surface Treatment | Zinc plating with yellow chromate (≥240h salt spray) |
| Weight (each) | ~2.3 kg |
The engine hanger plate is a safety-critical component that attaches to the cylinder block, providing a reliable lifting point for hoisting the engine during removal or installation. The Shacman 611600040076 plate is precision-forged to match the X5000 engine’s existing bolt hole pattern.
Using an incorrect or weak hanger plate can lead to slippage, engine drop, serious injury, and damage to fuel lines, wiring, and cooling components. The genuine Shacman plate is engineered to exceed international lifting standards.
During a full engine overhaul or chassis repair, the hanger plate allows technicians to safely support the engine weight without straining the front lifting eye or causing imbalance. It ensures a level lift, protecting the flywheel housing and front cover from distortion.
The 611600040076 engine hanger plate is hot-forged from high-grade carbon steel (SAE 1045 equivalent), which aligns the grain flow with the plate’s contours, maximizing strength without adding unnecessary weight. After forging, the plate undergoes normalization and tempering to achieve a uniform hardness of 25–30 HRC.
This heat treatment provides excellent toughness, preventing brittle fracture even if the plate is accidentally overloaded. Aftermarket plates are often cut from mild steel plate, which lacks the grain orientation and may bend or tear under load.
The lifting eye hole is precisely bored and deburred to prevent chafing of the lifting sling or chain. The surface finish is ground smooth to eliminate stress risers that could initiate cracks.
Shacman’s engine hanger plates are CNC-machined after forging to ensure precise hole locations and flatness. The mounting hole centers are held within ±0.2 mm, guaranteeing perfect alignment with the engine block’s threaded bosses. Misaligned aftermarket plates can cross-thread bolts or crack the block.
Each plate is 100% inspected for cracks using magnetic particle testing (MPI). Any plate showing surface or subsurface defects is immediately scrapped. This level of inspection is rarely performed on generic lifting brackets, which may contain hidden flaws.
After machining, the plate receives a uniform zinc plating with yellow chromate passivation, providing excellent corrosion resistance even when exposed to engine oil, coolant, and road salt. The coating thickness is verified with a magnetic gauge.
Representative samples from each production batch are subjected to a proof load of 2400 kg (two times the SWL) using a calibrated tensile testing machine. The plate must show no permanent deformation or cracking. A batch certificate is issued, documenting the test results and material heat number.
Fleets and repair shops can request these certificates for compliance with their internal safety programs. Genuine Shacman plates also carry a laser-etched part number for traceability.
Installing the 611600040076 engine hanger plate is straightforward. Locate the two M16 threaded holes on the side of the cylinder block (typically near the front or center of the engine). Clean the threads thoroughly using a tap to remove any debris or sealant.
Attach the plate using two new grade 10.9 M16 bolts, and torque to 210 Nm. Do not reuse old bolts, as they may have been stretched. Use a lifting sling or shackle through the 25 mm hole and ensure the lift is balanced before raising the engine.
This hanger plate is compatible with all Shacman X5000 models equipped with WP12 and WP13 engines, including Euro III through China VI variants. Always verify the OEM number 611600040076 before ordering.
Before each use, visually inspect the engine hanger plate for cracks, bending, or excessive wear around the lifting hole. Pay special attention to the area around the mounting holes for elongation or thread damage. Do not use the plate if any deformation is visible.
Store the plate in a dry area to prevent surface rust. If the zinc coating is damaged, touch up with zinc-rich paint. For professional workshops, it is recommended to recertify the hanger plate every two years or after any overloading event.
Genuine Shacman plates should be retired after 10 years of regular use or immediately if any damage is found. Replace with a new 611600040076 unit to maintain safety standards.
Using the correct engine hanger plate reduces the risk of engine slippage during removal, which can cause severe injuries. The wide, flat design spreads the lifting force evenly, preventing damage to the engine block’s mounting ears.
Incorrect lifting points can crack the timing cover or oil pan. The 611600040076 plate is engineered to lift the engine at the manufacturer-recommended attachment points, preserving the engine’s structural integrity.
Workshops that use genuine Shacman lifting equipment report fewer accidents and shorter engine swap times, as the plate allows for a quick and safe connection to the hoist.
Aftermarket engine hanger plates are often laser-cut from plain mild steel, lacking the necessary strength and impact resistance. They may also have imprecise hole locations, requiring force to install, which can damage the block threads.
Genuine Shacman plates are forged, heat-treated, and 100% crack-tested. The lifting eye is designed to accept standard 3/4″ shackles or chain hooks, providing compatibility with common shop equipment.
Using OEM parts ensures compliance with workplace safety regulations (OSHA, local standards) and protects your technicians from liability. Many insurance policies require the use of manufacturer-approved lifting attachments.
The cost of a genuine engine hanger plate is negligible compared to the cost of a dropped engine, which can exceed $20,000 in component damage plus injury claims. For a shop performing ten engine pulls per year, the genuine plate pays for itself in avoided risk.
Additionally, the precision fit of the OEM plate reduces installation time, allowing technicians to complete lifts faster. Aftermarket plates that require filing or reaming waste valuable labor minutes.
Over the life of the shop (10+ years), a single genuine plate can be used hundreds of times. Its durability far exceeds that of generic alternatives, making it the most economical choice in the long run.
Authorized Shacman parts distributors stock the 611600040076 engine hanger plate worldwide. Each plate is supplied in a labeled poly bag with the OEM number and batch code for traceability.
Bulk orders of 5, 10, or 20 plates are available for large workshop chains. Just-in-time delivery options help minimize inventory while ensuring lifting equipment is always on hand.
Always purchase from approved dealers to avoid counterfeit products. Genuine Shacman plates can be verified by the forged-in part number and the weight of the plate (aftermarket plates are often lighter due to thinner material).
The Shacman OEM 611600040076 Engine Hanger Plate is a small but critical component for safe and efficient engine handling. By providing a forged, tested, and precisely machined lifting point, this genuine part protects technicians, prevents engine damage, and speeds up repairs. For Shacman X5000 heavy-duty trucks, choosing the original 611600040076 engine hanger plate is an investment in workshop safety and operational excellence. Trust only genuine Shacman – lifting with confidence, every time.
