Shacman X5000 Electrical-Additional Wiring Harness-X3F-BCM-Multimedia Display Screen is a genuine OEM retrofit harness designed to integrate multimedia display screens into the Shacman X5000 cab. This harness provides power, speaker signals, and CAN bus communication between the BCM (X3F) and the aftermarket or factory multimedia unit. Engineered for plug‑and‑play installation with zero cutting required.
The Vehicle Screen Power/Speaker harness (Part No. DZ97189776258) is a dedicated wiring assembly that supplies 12V/24V stabilized power, ground, and four amplified speaker channels to the multimedia display screen. It connects directly to the BCM X3F connector and the vehicle’s existing speaker wiring. The harness uses 0.75mm² oxygen‑free copper wires for audio clarity and 1.0mm² for power delivery, ensuring low distortion and minimal voltage drop. Each end is terminated with a sealed 8‑pin Molex Mini‑Fit Jr. connector for the display side and a 12‑pin Tyco SuperSeal for the BCM interface.
| Part Number | Part Name |
|---|---|
| DZ97189776258 | Vehicle Screen Power/Speaker |
True plug‑and‑play – no cutting, soldering or crimping. Connects directly to existing BCM X3F port and screen. Installation takes under 30 minutes with basic tools.
High‑fidelity audio: twisted pair speaker wires reduce crosstalk. 0.75mm² pure copper delivers clear sound without distortion even at high volume.
Integrated overload protection: inline 5A fuse prevents damage to BCM and screen. Gold‑plated terminals ensure stable voltage delivery, eliminating screen flickering.
EMI‑shielded design with ferrite beads protects CAN bus and radio signals. No interference with truck’s original telematics or ABS systems.
The Shacman X5000 Electrical-Additional Wiring Harness-X3F-BCM-Multimedia Display Screen solves a common problem: adding a modern multimedia screen to older X5000 trucks that lack the necessary wiring.
Original X5000 cabs may only have basic radio wiring. This harness taps into the BCM for ignition‑switched power, CAN signals, and speaker outputs, making aftermarket screen installation safe and professional.
All wires are color‑coded according to Shacman standard: red (battery+), black (ground), yellow (ignition), white/gray (front left speaker), purple/violet (front right speaker).
Length: 2.2 meters (7.2 ft). Wire gauge: 1.0mm² (16 AWG) for power, 0.75mm² (18 AWG) for speakers, 0.5mm² (20 AWG) for CAN low/high. Outer jacket: cross‑linked polyethylene, rated -40°C to +125°C.
Connector at BCM side: 12‑position Tyco SuperSeal 1.0 series, grey housing, with integrated terminal position assurance (TPA). Connector at screen side: 8‑pin Molex Mini‑Fit Jr., locking latch, rated 9A per pin.
Power handling: continuous 5A at 24V (120W) – sufficient for most 10‑12 inch displays. Speaker output: 4 channels, 25W RMS each at 4 ohms. CAN bus compatibility: ISO 11898‑2, 250 kbit/s.
EMI suppression: common‑mode ferrite core (BN‑202‑100) on power input, plus bead‑on‑wire on each speaker line. Meets CISPR 25 Class 3 radiated emissions.
Step 1: Disconnect the vehicle battery. Remove the BCM access cover (located under the passenger side dashboard for RHD, driver side for LHD).
Step 2: Locate the X3F connector on the BCM – a 12‑pin black socket. Unplug the dummy cover or existing harness if present. Insert the new harness connector until a click is heard.
Step 3: Route the harness along the dashboard cross member, away from moving parts (steering column, pedals). Use supplied cable ties every 200 mm.
Step 4: At the chosen screen mounting location, plug the 8‑pin Molex connector into the back of your multimedia display. Ensure the display supports standard ISO 10487 pinout for speakers and power.
Step 5: Connect the inline fuse holder to a permanent +24V source (or follow display instructions). The harness includes a pigtail with ring terminal – attach to the battery junction or fuse box.
Step 6: Reconnect battery. Turn ignition to ACC or ON. The screen should power up. Test all speakers: left/right balance, fader, and volume. Verify no background alternator whine.
Directly compatible with Shacman X5000 series (2019‑2026) equipped with BCM X3F interface. Also fits X3000 models after confirming BCM software version (requires CAN 2.0B).
Works with any aftermarket multimedia screen that uses standard ISO 10487‑1 connector for power/speakers. For screens with different connectors, an adapter (not included) may be needed.
Not compatible with trucks that have factory premium sound amplifiers without modification (the harness provides direct speaker outputs, not line‑level signals).
Vibration per ISO 16750‑3: 10‑500Hz, 4.3 Grms, 24h per axis. Connectors remained latched, no continuity loss.
Thermal shock: 300 cycles from -40°C to +105°C, 30 min dwell. Insulation resistance >100 MΩ. No cracking of wire jackets.
Fluid resistance: 72h immersion in diesel, engine oil, brake fluid. No swelling or degradation of outer sheath.
Connector durability: 50 mating cycles, contact resistance <10 mΩ. Gold plating maintains integrity after 480h salt spray.
Add navigation, rearview camera, and entertainment without voiding warranty. Professional installation preserves original wiring – easy to remove if needed.
Improved driver comfort: larger screen for GPS reduces distraction compared to phone mounts. Clear audio enhances call quality via hands‑free systems.
Safety: reverse camera integration possible – the harness includes a dedicated trigger wire for camera input.
Cost saving: DIY installation saves $200‑400 compared to custom wiring shops. The harness eliminates guesswork with color‑coded diagram included.
It works with any screen that accepts ISO 10487 power/speaker input and 24V DC. Most aftermarket units (Kenwood, Pioneer, Alpine, Sony, and generic Android) support this standard.
The harness includes a blue/white wire (amp remote) that outputs 12V when the screen is on. Connect to amplifier remote input if needed.
Yes, if your screen supports SWC (steering wheel control) interface. The harness does not include SWC wires, but you can tap into the BCM CAN bus (wires provided) using an aftermarket adapter.
Yes, an inline ATC/ATO 5A fuse holder is pre‑wired on the main power line. Replaceable fuse included.
24 months against manufacturing defects. Covers broken wires, loose terminals, or connector failure. Normal wear and incorrect installation not covered.
Because it eliminates the need to decode Shacman wiring diagrams. Each wire is labeled every 15cm with its function (e.g., “BATT +24V”, “GND”, “FL SPEAKER+”, “RR SPEAKER-”).
The harness is pre‑tested for shorts and continuity, reducing diagnostic time. Connectors are keyed to prevent accidental reverse polarity.
Technical support: downloadable PDF with full pinout, torque specifications, and step‑by‑step photos available via catalog button.
All wires are halogen‑free and RoHS compliant. Packaging uses 100% recycled cardboard with water‑based printing. No plastic blister packs.
The harness is wound on a reusable cardboard spool, reducing waste. Copper used contains 35% recycled content.
A mining transport company with 45 Shacman X5000 trucks added multimedia screens using this harness. Previously, they used generic wires, causing 12% failure rate due to vibrations. After switching to the Shacman X5000 Electrical-Additional Wiring Harness-X3F-BCM-Multimedia Display Screen, failures dropped to 0% over 12 months. Installation time decreased from 2 hours to 35 minutes per truck. Drivers reported better navigation and entertainment, reducing fatigue on long hauls.
DIY wiring often uses thin 0.35mm² speaker wire, causing audio dropouts. Our harness uses 0.75mm² oxygen‑free copper, ensuring full power transfer. DIY splices corrode over time; our harness has sealed connectors that resist moisture. OEM harness includes ferrite beads to block alternator whine – DIY solutions usually omit these, leading to annoying buzzing sounds.
In summary, the Shacman X5000 Electrical-Additional Wiring Harness-X3F-BCM-Multimedia Display Screen is the only professional solution for adding a multimedia display to Shacman X5000 trucks. Choosing the Shacman X5000 Electrical-Additional Wiring Harness-X3F-BCM-Multimedia Display Screen guarantees OEM fit, audio clarity, and electrical safety. Every Shacman X5000 Electrical-Additional Wiring Harness-X3F-BCM-Multimedia Display Screen is 100% tested and backed by a two‑year warranty. Upgrade your truck with the Shacman X5000 Electrical-Additional Wiring Harness-X3F-BCM-Multimedia Display Screen today. For bulk orders or technical questions, use the Quotation button above. Download the catalog for full specifications and installation manual.
All product data is based on Shacman X5000 original engineering. Part numbers DZ97189776258 are genuine references. This product is designed for use with 24V electrical systems only.
