Central Electrical Device Board
Центральный электрический щит
Tablero eléctrico central
The genuine Shacman X5000 Central Electrical Device Board with OEM number DZ97189584361 is the integrated body control module (BCM) and power distribution center that manages all essential electrical functions on the X5000 heavy‑duty truck. This advanced unit combines fuse and relay management with sophisticated electronic control for lighting, wipers, windows, door locks, and exterior mirrors. Designed to meet Shacman’s stringent reliability standards, DZ97189584361 ensures seamless communication between the vehicle’s ECU and various body systems, providing precise control and diagnostics for enhanced operational efficiency.
Manufactured from high‑temperature, flame‑retardant polymer with precision‑molded connector ports, this board is built to withstand the rigorous demands of heavy‑duty trucking. Its robust circuitry and gold‑plated terminals guarantee low‑resistance connections and immunity to vibration, moisture, and temperature extremes. Every mounting hole and connector interface matches the original dashboard and firewall layout, enabling a direct, plug‑and‑play installation without wiring modifications. This board is essential for restoring full electrical functionality after water ingress, damage, or when upgrading the vehicle’s electronic architecture.
Each unit is 100% functionally tested and validated for CAN bus communication, fuse integrity, and relay operation. Choose genuine Shacman quality for reliable, long‑lasting central electrical management on your X5000.
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ97189584361 |
| Product Name | Central Electrical Device Board / BCM & Fuse/Relay Hub |
| Brand | Shacman (Genuine OEM) |
| Application | Shacman X5000 – Dashboard‑mounted BCM and power distribution |
| Input Voltage | 12V DC (vehicle battery) |
| Max Current Rating | 160 A (total system) |
| Fuse Slots | 26 (mini‑blade and JCASE types) |
| Relay Sockets | 14 (micro ISO relays) |
| Communication Protocol | CAN bus (J1939) and LIN bus |
| Housing Material | High‑temperature, flame‑retardant polyamide (UL 94 V‑0) |
| Operating Temperature | -40°C to +105°C |
| Weight (approx.) | 1.7 kg |
| Standards | ISO 9001, IATF 16949, SAE J1939, Shacman Q/SC 812 |
The Shacman central electrical device board DZ97189584361 is a state‑of‑the‑art electronic module that integrates the body control module (BCM), power distribution, and all cab electrical interfaces into a single compact unit. The board features a multi‑layer PCB with heavy‑duty copper traces for high‑current paths and fine‑pitch signal routing for low‑level control circuits. Its microcontroller is programmed with the latest factory logic for lighting sequences, wiper control, door lock actuation, and mirror adjustment, ensuring seamless operation with all X5000 body systems. The housing is constructed from a high‑temperature polyamide that resists deformation and flame, and the connector pins are gold‑plated to ensure low‑resistance, corrosion‑free contacts that maintain signal integrity over millions of cycles.
Each board is 100% functionally tested on a dedicated test bench that simulates the entire vehicle electrical system. The test verifies all outputs (lights, relays, motors) and inputs (switches, sensors, CAN messages) to ensure flawless operation. Random samples are subjected to thermal shock (-40°C to +105°C, 500 cycles), vibration (20G, 10‑2000 Hz), and humidity cycling (95% RH, 40°C for 240 hours) to validate long‑term reliability. The device board is also protected against reverse polarity and transient voltage spikes, ensuring that it withstands the harsh electrical environment of a heavy‑duty truck.
By consolidating all fuses, relays, and the BCM into a single unit, the DZ97189584361 eliminates the need for separate fuse boxes and control modules scattered throughout the cab. This centralized approach simplifies wiring, reduces weight, and improves diagnostic efficiency. The board’s CAN bus interface allows the vehicle’s main ECU to communicate seamlessly, enabling features like load shedding, battery protection, and remote diagnostics.
The central electrical device board is the nerve center of the X5000’s electrical system. It controls every lighting function (headlights, turn signals, brake lights, interior lights), every power window and door lock, the wiper and washer systems, and the exterior mirror adjustments. A faulty board can cause a cascade of failures, from non‑functional turn signals to complete loss of cab power, creating serious safety hazards. The DZ97189584361 board is designed with redundant power paths and built‑in diagnostic routines that can detect and report faults via the CAN bus, allowing for rapid troubleshooting. Its high‑quality relays and solid‑state switches are rated for millions of operations, ensuring long service life.
In addition to its functional role, the board’s intelligent power management protects the vehicle’s battery from excessive drain. It can automatically shed non‑essential loads when battery voltage drops, preventing starting issues. The board also stores fault codes and can be interrogated using a diagnostic tool, greatly reducing the time needed to identify electrical problems. Fleet operators will appreciate the reliability and serviceability that this genuine Shacman board provides, as it minimizes downtime and ensures that all cab electrical systems work as intended.
With its integrated BCM logic, the DZ97189584361 ensures that the headlights turn on and off at the correct times, the wipers respond instantly to the switch, and the doors lock and unlock without delay. This reliability is crucial for driver safety and convenience, especially in harsh weather conditions where reliable lighting and wipers are essential.
Installing the Shacman central electrical device board DZ97189584361 requires careful handling to avoid damaging the sensitive electronic components. Disconnect the vehicle’s battery and remove the old board (if present) by unplugging all harness connectors and unbolting the mounting screws. Clean the mounting area, then position the new board, ensuring all connectors align with their respective harnesses. Plug in each connector until it clicks securely, then secure the board with the original screws, torquing to 5‑8 Nm. Reconnect the battery and verify that all electrical functions operate correctly – lights, wipers, windows, locks, and mirrors. If the vehicle is equipped with a BCM, the board may require a short initialization procedure (typically performed automatically).
This board is compatible with all Shacman X5000 models from 2015 onward, including the X5000 M12, heavy‑haul, and construction variants, as well as trucks with various lighting and convenience options. It directly replaces original part numbers DZ97189584360 and DZ97189584362. Applications include the main fuse and relay board in the dashboard area. Always verify the OEM marking DZ97189584361 on the board label before installation. If the vehicle has been modified with additional electrical accessories, ensure that the total current draw does not exceed the board’s capacity.
Keep a spare DZ97189584361 board in your parts inventory for quick replacement in case of failure. After installation, perform a full function test of all cab electrical systems and check for any diagnostic trouble codes using a suitable scan tool. Periodically inspect the board for signs of water ingress, corrosion, or overheating.
Periodically inspect the board’s connector pins for corrosion or bent terminals. Ensure that the board is free of dust and moisture. If the vehicle experiences unexplained electrical issues, check the board’s fuses and relays for failure. The board is designed to be maintenance‑free; however, if the vehicle is used in extreme conditions, more frequent inspections may be warranted. Always use genuine Shacman fuses and relays for replacement.
Shacman X5000 trucks operate in a wide range of demanding applications, from construction and mining to long‑haul freight. The central electrical device board DZ97189584361 is designed to withstand the harsh conditions encountered in these environments. Its high‑temperature polyamide housing resists heat, oil, and chemicals, and the sealed connector system prevents moisture and dust ingress. The board is tested to operate reliably from -40°C to +105°C, making it suitable for both arctic and desert climates. In mining and construction trucks, where vibration is constant, the board’s rugged construction and secure mounting prevent intermittent faults. For highway fleets, the board provides reliable electrical management, reducing the risk of breakdowns caused by electrical failures.
The board’s integrated BCM also supports advanced features such as automatic headlight activation, rain‑sensing wipers (when equipped), and programmable lighting sequences. These features enhance driver convenience and safety. By using the genuine Shacman board, fleet operators avoid the reliability issues common with aftermarket or refurbished units, which may have corrupted software or inferior components. The DZ97189584361 board is backed by Shacman’s quality assurance, providing peace of mind for operators who depend on their vehicle’s electrical system for safety and performance. Its long service life and resistance to environmental factors contribute to a lower total cost of ownership.
1. Integrated BCM & power distribution: Combines control and fusing in one unit for simplified architecture. 2. Superior materials: Flame‑retardant housing and gold‑plated connectors ensure long‑term reliability. 3. Full diagnostic capability: CAN bus communication enables remote troubleshooting and fault logging. 4. Plug‑and‑play installation: Exact fitment with factory connectors, no wiring modifications needed. 5. Full traceability: Batch‑coded with software version and test report.
Aftermarket boards often use inferior components or lack proper software calibration, leading to intermittent faults or feature incompatibility. The genuine Shacman board’s premium materials and exact engineering ensure reliable, long‑lasting performance. Investing in DZ97189584361 protects your vehicle’s electrical system, reduces downtime, and maintains a professional installation. For fleets, standardizing on genuine boards ensures consistent electrical performance and simplifies parts management.
Electrical failures can lead to costly roadside repairs and downtime. By using the DZ97189584361, you prevent these issues. The board’s long life and reliability reduce the frequency of replacements, saving labor and parts costs over the vehicle’s lifetime. Its diagnostic capabilities also speed up troubleshooting, further reducing repair times.
Shacman’s central electrical device board DZ97189584361 is produced in an IATF 16949 certified facility. The PCB is manufactured with high‑grade FR‑4 material and assembled using surface‑mount technology (SMT) with automated optical inspection (AOI). The microcontroller is programmed with the latest factory firmware, and the board is subjected to a 100% functional test that simulates all vehicle inputs and outputs. The housing is injection‑molded from UL 94 V‑0 polyamide, and the connector pins are gold‑plated to a thickness of 0.8 µm. Each board is inspected for solder joint integrity, connector seating, and mechanical dimensions. Random samples are subjected to thermal cycling, vibration, and humidity testing to validate durability. Only boards that pass all criteria are labeled with the OEM part number and packed in anti‑static bags.
This rigorous quality system ensures every DZ97189584361 board performs identically to the original factory component. Consistency is critical for maintaining electrical system reliability and preventing faults across your entire fleet. The facility also complies with REACH and RoHS environmental regulations, using only lead‑free, water‑based materials.
Genuine Shacman central electrical device board DZ97189584361 is stocked by authorized distributors worldwide. Parts are supplied in sealed anti‑static bags, individually boxed with installation instructions, labeled with OEM part number and batch traceability. Bulk packs of 5 boards are available for fleet maintenance depots. Expedited shipping options are available through Shacman’s regional logistics hubs in North America, Europe, Asia, Africa, and the Middle East, with typical delivery within 3‑5 business days. Always purchase from certified dealers and verify the holographic authenticity label. Counterfeit boards may have incorrect firmware, missing components, or poor solder quality, leading to immediate failures.
For preventive maintenance programs, automated replenishment ensures your workshop never runs out of essential electrical boards. Keep a stock of DZ97189584361 on every service truck to handle electrical system repairs or board replacements in the field. Many fleets replace these boards as part of a scheduled electrical system inspection to ensure reliable operation.
The Shacman Central Electrical Device Board DZ97189584361 is a precision‑engineered integrated BCM and power distribution hub that manages all cab electrical functions on X5000 trucks. With robust construction, advanced diagnostics, and exact fitment, this genuine OEM board ensures reliable lighting, wiper, door, and mirror control, enhancing driver safety and comfort. By choosing DZ97189584361, you protect your vehicle’s electrical system and ensure dependable operation. Don’t trust generic substitutes – insist on genuine Shacman quality for every central electrical board replacement.
