Shacman X5000 Electric Flipper 75 is a complete electrical upgrade solution for heavy‑duty trucks, integrating a 40A fuse, a new electric flip chassis harness (fender/firewall mounted), and an electric flip instrument panel sub‑assembly harness. This kit ensures reliable cab tilting operation and modernized wiring for Shacman X5000 series, minimizing electrical failure and maximizing uptime.
The 40A Fuse (DZ97189584369) is a high‑interrupting capacity blade fuse designed to protect the electric flip circuit from overcurrent spikes. It features a transparent housing for visual inspection and is rated for 32V DC. The fuse element is made of silver‑plated zinc, ensuring low voltage drop and rapid melting under short circuit conditions. Direct replacement for Shacman X5000 flip system, compatible with standard ATO/ATC fuse blocks. Ideal for protecting the cab tilt motor and solenoid.
The New Electric Flip Chassis Harness (DZ97189779084) is routed along the fender and firewall, connecting the battery junction box to the cab tilt pump motor. Made of 2.5mm² cross‑linked polyethylene wire, it withstands under‑hood temperatures up to 125°C. Sealed Deutsch connectors prevent moisture ingress, while the integrated 40A fuse holder ensures serviceability. This harness replaces original corroded or damaged wiring, restoring reliable cab lifting functionality. Pre‑molded retention clips match factory mounting points on the X5000 chassis.
The Electric Flip Instrument Panel Sub Assembly Harness (DZ97189776924) provides the in‑cab interface for the electric flipper control. It connects the rocker switch, indicator light, and interlock safety circuit to the main chassis harness. Features 0.75mm² thin‑wall PVC wires, color‑coded per Shacman schematic. The harness includes a 6‑pin Molex MX150 connector for dashboard integration and a protective foam wrap to eliminate rattles. Allows drivers to operate the cab tilting function with a single button, with LED status feedback.
| Part Number | Part Name |
|---|---|
| DZ97189584369 | Fuse (40A) |
| DZ97189779084 | New Electric Flip Chassis Harness (Mounted On Fender/Firewall) |
| DZ97189776924 | Electric Flip Instrument Panel Sub Assembly Harness |
OEM exact fit – every harness and fuse matches Shacman X5000 original dimensions and connector positions. No cutting, soldering, or zip‑tie improvisation needed. Plug‑and‑play replacement reduces downtime to 45 minutes.
Extreme durability: chassis harness rated for -40°C to +125°C, oil‑resistant jacket, and 480h salt spray tested. Eliminates brittle wires and corrosion that cause intermittent cab tilt failures.
Integrated 40A fuse provides direct overcurrent protection. Blown fuse condition is easily diagnosed with the transparent housing. No additional fuse blocks or inline holders required.
Safety interlock compatible – the instrument panel harness includes a dedicated circuit for parking brake and neutral position detection, preventing accidental cab tilting while driving.
The Shacman X5000 Electric Flipper 75 solution replaces two critical wiring assemblies and the high‑current fuse, restoring full electric cab tilting functionality.
Original X5000 chassis harnesses often suffer from heat aging, leading to brittle insulation and open circuits. Our upgraded harness uses cross‑linked polyethylene with 125°C continuous rating.
Kit includes both underhood and dashboard wiring, ensuring a comprehensive repair. No need to buy separate components – everything arrives in one box.
The chassis harness (DZ97189779084) length: 2.6 meters. It runs from the battery positive terminal (via 40A fuse) to the cab tilt pump motor located on the right chassis rail.
Wire color coding: red/black for main power, blue/white for control signal to the solenoid, and black for ground. Each wire strand has tin plating for corrosion resistance.
Connector types: chassis side uses a 2‑pin Superseal 1.5 series for the pump motor; the firewall end uses a 3‑pin DT series connector linking to the cab harness.
The instrument panel sub‑assembly harness (DZ97189776924) is 1.2 meters long. It connects to the electric flip rocker switch (not included) and splices into the dashboard backlighting.
Terminal material: brass with 3µm tin over nickel. Pull‑out force exceeds 8kg per terminal, ensuring vibration resistance on rough roads.
Step 1: Disconnect both batteries (ground first). Remove the old 40A fuse from the PDU and discard if blown or corroded.
Step 2: Locate the original electric flip chassis harness along the left fender. Unplug both ends – at the battery junction and at the pump motor. Remove old harness and clips.
Step 3: Install the new chassis harness (DZ97189779084) using the same routing path. Secure with supplied nylon push‑mount ties every 200mm. Connect the fuse holder to the battery terminal.
Step 4: Inside the cab, remove the lower dash panel. Unplug the old instrument panel harness from the flip switch and BCM (body control module). Replace with new sub‑assembly harness (DZ97189776924).
Step 5: Insert the 40A fuse (DZ97189584369) into the holder. Reconnect batteries. Test: with parking brake set and transmission neutral, press the flip switch – the cab should lift.
Step 6: If the pump runs but cab does not move, check hydraulic fluid level. If no pump sound, verify fuse continuity and ground connections.
No response from cab tilt switch: often caused by broken wires inside the chassis harness due to flexing. Our replacement harness uses extra flexible stranding (Class K) to resist metal fatigue.
Intermittent operation: usually due to corroded connectors. The sealed Deutsch and Superseal connectors on our harnesses eliminate moisture ingress and fretting corrosion.
Fuse blows repeatedly: may indicate pump motor short circuit. However, after motor replacement, the old harness may have damaged insulation – our new harness restores safe isolation.
Dashboard switch lights up but no tilt: the instrument panel harness includes a dedicated ground return path, fixing poor grounding issues common in older X5000 cabs.
Thermal aging test: 3000 hours at 125°C followed by cold bend at -40°C. No cracking of insulation or change in conductor resistance.
Vibration per ISO 16750‑3: 24 hours random 5–2000Hz, 4.3 Grms. Connectors remained latched, no intermittent continuity loss detected.
Fluid resistance: 7 days immersion in diesel, engine oil, brake fluid, and coolant. Harness jacket showed <3% swell and no tackiness.
Fuse performance: 40A fuse clears a short circuit in less than 1ms at 14V (12V system) and 28V (24V system). Arc quenching time within UL 248 standard.
Direct fit for Shacman X5000 series produced from 2019 to 2026, including tractor heads, dump trucks, and concrete mixers equipped with electric cab tilt.
Also compatible with X3000 models after minor connector adaptation (contact technical support for pinout). Not for manual‑hydraulic tilt cabs without electric pump.
Check your existing fuse rating: the original system uses a 40A fuse. If your truck has a 30A or 50A fuse, verify pump motor specification before installation.
Reduced repair cost: replacing both harnesses and fuse costs 70% less than dealer wiring repair plus labor. One kit covers all common electrical failure points.
Minimized downtime: average installation 1 hour by a competent technician. No special tools required beyond basic hand tools and wire strippers.
Improved safety: new wiring eliminates risk of electrical fire due to chafed wires grounding against chassis. The 40A fuse provides reliable overcurrent protection.
Enhanced diagnostics: fresh harness color coding matches factory schematics, making future troubleshooting faster. Each wire is imprinted with circuit ID every 300mm.
Yes. The harness and fuse are rated for 12V and 24V systems. Pump motor voltage must match the truck; the wiring is compatible with both.
No. The instrument panel harness connects to your existing flip switch. If the switch is damaged, order separately (Part DZ97189584012).
24 months unlimited mileage. Covers manufacturing defects, broken terminals, fuse failure due to internal fault. Does not cover pump motor or hydraulic components.
Measure voltage at pump motor connector while pressing flip switch. If no voltage but the dashboard switch illuminates, the chassis harness is likely broken. Our kit directly replaces it.
Yes, each connector cavity is pre‑filled with dielectric silicone grease to prevent water wicking and terminal corrosion.
Because the original harnesses degrade after 4-5 years due to engine heat. The new cross‑linked polyethylene extends life to 10+ years. Labour time is halved thanks to pre‑formed shapes.
Each harness is tested on a jig that simulates the X5000 cab geometry. No trimming or modification needed – they bend exactly where required.
Backed by online PDF installation guide with color photos and torque specs. For bulk fleet orders, we provide laminated quick reference cards.
All wires are manufactured with lead‑free PVC and halogen‑free XLPE. RoHS compliant (Directive 2011/65/EU). Fuse ceramic body is recyclable as general waste.
Packaging uses 90% recycled cardboard and compostable bags. No styrofoam. The harness cardboard spools are FSC certified.
By refurbishing aging trucks with this kit, you extend vehicle life and avoid premature scrapping, reducing overall carbon footprint per truck.
A mining fleet of 45 Shacman X5000 trucks experienced 18 failures of the electric flip system over 6 months, each causing 2 hours downtime. After installing the Shacman X5000 Electric Flipper 75 kit on all trucks, failures dropped to zero in the following year.
Downtime savings estimated at 36 hours per month. The standardized repair procedure also simplified spare parts inventory: one SKU replaced three separate part numbers.
Generic wiring uses PVC automotive wire rated only 80°C, leading to early embrittlement. Our harness uses 125°C XLPE, proven for underhood longevity.
Aftermarket connectors often lack environmental seals, causing corrosion after one winter. Our kit uses OEM‑grade Deutsch and Superseal connectors with silicone seals.
Including the correct 40A fuse ensures proper overcurrent protection. Most generic repairs reuse old or wrong fuse rating, risking fire. Our kit includes a fresh, calibrated fuse.
In summary, the Shacman X5000 Electric Flipper 75 delivers a factory‑grade electrical restoration for cab tilting systems. Choosing the Shacman X5000 Electric Flipper 75 ensures reliable operation, safety, and easy installation. Every Shacman X5000 Electric Flipper 75 component meets original equipment standards and is backed by a two‑year warranty. Upgrade your truck with the Shacman X5000 Electric Flipper 75 kit today and eliminate frustrating electrical gremlins. For bulk orders, use the Get Quotation button above. The Shacman X5000 Electric Flipper 75 is available from global warehouses with fast shipping.
